WOLF TOOTH SRAM BOOST DIRECT MOUNT CHAINRINGS
Direct Mount Chainrings for SRAM Cranks BOOST / 3mm Offset
Compatibility
- These direct mount chainrings will replace your existing chainring and spider or replace the direct mount ring on SRAM cranksets including the DUB cranks. The ring is attached via 3 bolts on the back side of the spider near the spindle. Note that the SRAM 12spd Red and Force AXS use a different 8 bolt mounting interface that is not compatible with these chainrings.
- Wolf Tooth’s patented Drop-Stop® wide/narrow tooth profile for the ultimate chain retention and mud shedding ability
- 9, 10, 11, & 12spd Eagle - These chainrings are designed to work with all 9 speed, 10 speed, and 11 speed chains. They also work with 12 speed Eagle and 12 speed KMC chain. They do not work with Shimano 12 speed Hyperglide+ chain or SRAM 12 speed Flattop chain.
Webshops and Bike shops
Related Products
-
Description
Wheels MFG C/ring Inner 2.2mm Spacer(20)
2.2mm chainring spacer for inner position. Machined to close tolerances out of 6061 aluminum. Excellent for improving chain line, or for replacing missing spacers.
Inner Diameter: 8mm
Thickness: 2.2mm
20/bag -
Description
Wheels MFG C/ring Inner 4.0mm Spacer(20)
4.0mm chainring spacer for inner position. Machined to close tolerances out of 6061 aluminum. Excellent for improving chain line, or for replacing missing spacers.
Inner Diameter: 8mm
Thickness: 4.0mm
20/bag -
Description
This 94 BCD 5-bolt ring will serve all your Vintage crankset and Surly crankset needs.
- Fits any 94 BCD 5-bolt crankset
- Drop-Stop technology. On Wolf Tooth’s patented wide/narrow chainring, the wide side of the tooth has maximum contact on the drive side which spreads the load and improves chainring life. The narrow side allows clearance for mud and debris which reduces friction.
- Alternating wide/narrow tooth pattern prevents chain derailment
Compatibility
- Four of the holes are threaded and one is a normal through bolt hole (done for Surly compatibility). Use a stock 10mm chainring bolt for the fifth, hidden arm.
- These rings fit any 94 BCD 5 bolt crankset
- For Plus size bike applications with the Surly OD crankset, e.g. Instigator and Krampus, you will need to use the stock spacers (Spacer Kit QBP Part number CR8609) that came with your 1x setup. You will also need some 16mm bolts which can be purchased from Problem Solvers.
- For 1x9, 1x10, 1x11 and 1x12 drivetrains (including SRAM Eagle)
Compatible with all 10, 11, and 12-speed chains except Shimano 12-speed chains.
If using a 9-speed drivetrain use a 10-speed chain (shifts and works well on a 9-speed drivetrain and fits the ring tighter for better chain retention).
- Provides a great chainline on most boost bikes.
- Chainline (approximate as BB centering and cranksets vary) -
Description
Wolf Tooth Direct Mount Chainrings for Shimano E-Bike Motors have a 55mm chainline and are compatible with all Boost and Super Boost bikes that use the Shimano EP8, E8000, and E7000 e-bike motor splines.
- The Drop-Stop B tooth profile is compatible with almost all 9-, 10-, 11-, and 12-speed chains – the only exception is Shimano Hyperglide+.
- The Drop-Stop ST tooth profile is only compatible with Shimano Hyperglide+ chains.
- Direct Mount Chainrings for Shimano E-Bike Motors are machined with 7075-T6 aluminum at Wolf Tooth in Minnesota, USA. -
Description
104 BCD is the most common bolt pattern on double and triple cranksets and happens to be the first product ever made my Wolf Tooth Components. The Drop-Stop® tooth design is the best performing and longest lasting wide/narrow chainrings on the market.
- Fits any 104 BCD crankset
- Drop-Stop technology. On Wolf Tooth’s patented wide/narrow chainring, the wide side of the tooth has maximum contact on the drive side which spreads the load and improves chainring life. The narrow side allows clearance for mud and debris which reduces friction.
- Alternating wide/narrow tooth pattern prevents chain derailment
- Drop-Stop B
Compatible with all 9,10,11spd chains
12spd Chains: SRAM Road & Transmission (T-Type) Flattop chains
SRAM Eagle
KMC
Connex
Wipperman
Campagnolo
