Soma
-
Stock Code:SMFK230060
Matching fork for the Soma Jawbone A-Type frame.
- Tange CrMo steel
- Steve Potts Type II-R construction
- Axle to Crown: 420mm
- Rake: 50mm
- Investment cast thru-axle dropouts (12mm x 100mm)
- One set of cargo cage bosses per leg, lowest boss can be used for a pannier rack
- IS disc mount
- Sage Green w/ black
If you are getting this fork for the Jawbone, you need a ZS44 headset.
* Since this is for matching to a frame, we reserve the right to restrict sales of this item to customers who are buying a frame.POA -
Stock Code:SMFR900151Stock Code:SMFR900152Stock Code:SMFR900153Stock Code:SMFR900154Stock Code:SMFR900155Stock Code:SMFR900156Stock Code:SMFR900157
The Jawbone B-Type frame is a versatile platform to build drop bar mountain touring and bike packing rig. While it is still game for riding some gravel and singletrack, it it is its element when loaded up for your next adventure.
- Tange Prestige heat-treated double butted CrMo steel; butted CrMo rear end
-IRD Broski Sliding Dropouts allows for running derailleurs as well as geared hubs like Rohloff. You can also convert it to single speed if your derailleur conks out on a ride.
(Stock dropout insert is for 135mm QR. 142 x 12mm Thru-Axle inserts available separately)
- IS mount disc brake tabs
- Front derailleur compatible (bottom pull)
- Rear rack and fender eyelets
- Two sets of bottle cage bosses; one set of cargo cage bosses on downtube
- 44mm headtube fit 1-1/8" steerer tubes and tapered steerer tubes with a headset swap (Run a ZS44 headset with the matching fork)
- 27.2mm post size/28.6mm frt. der. size/29.8mm seat collar, 73mm bottom bracket (English threads)
- Tire width range: 650b x 47mm to 27.5 x 2.6” / 700c x 38mm to 29 x 2.25” - Color: Slick Black
- Sizes: 650b only: 50cm, 52cm 700c: 54cm, 56cm, 58cm, 61cm, 64cm
Optional Fork Features
- Tange CrMo steel
- Fits QR hubs
- Axle to Crown: 420mm
- Rake: 50mm
- IS disc mounts, rotor fit up to 180mm
- Two sets of cargo cage bosses per leg, pannier rack bosses on inside and outside legPOAPOAPOAPOAPOAPOAPOA -
Stock Code:SMFK230062
Matching fork for the Soma Jawbone B-Type frame.
- Tange CrMo steel
- Fits QR hubs
- Axle to Crown: 420mm
- Rake: 50mm
- IS disc mounts, rotor fit up to 180mm
- Two sets of cargo cage bosses per leg, pannier rack bosses on inside and outside leg
- Two sets of fender/rack eyelets at fork ends
If you are getting this fork for the Jawbone, you need a ZS44 headset.
*Since this is for a frame and we have limited quantities, we reserve the right to restrict sales to only customers purchasing the Jawbone frame.POA -
Stock Code:SMFR903202
The Juice is our trail/XC hardtail frame for 29" wheels. This updated version features tough Broski Sliding Dropouts that allow you to go single-speed or geared or even run hub gears and slightly more modern geometry. Also new is internal seat tube dropper post routing. A modified chainstay allows fitting even some double cranks with “plus size” 2.8" wide tires without needing to invest in Boost 148 parts. We even offer a belt-drive ready version if you want to run a Gates Carbon Drive. (*Belt-drive version works with regular chains as well)
– Tange Prestige heat-treated butted CrMo steel; butted CrMo rear end
– Geometry is optimized for 100mm travel 29" forks and will handle 120mm forks great, too (Ideal rigid fork length: 485mm)
– Disc brakes only (ISO tabs)
– Standard or Belt-Drive compatible versions available (split for installing belt is on the seatstay.)
– IRD Broski Sliding Dropouts allows geared and single-speed builds with easy wheel removal
– In 2021 these come ready for 142 x 12mm Thru-Axle hubs. (Can be converted to 135mm spacing for traditional QR hubs with IRD aftermarket inserts)
– S-bend seatstays and chainstays
– Rear rack and fender eyelets
– CNC-machined 44mm headtube: Will take 1-1/8" steerers with a ZeroStack 44 headset or tapered steerers with a ZS44 upper assembly and external cup (EC44) lower assembly
– 31.6mm post size/34.9mm frt. der. size/34.9mm seat collar/73mm bottom bracket (English threads); 400mm+ post recommended
– Recommended tire size: 29" x 2.4" (or 27.5 x 2.8”)$2,150.00 (RRP) -
Stock Code:SMFR903201
he Juice is our trail/XC hardtail frame for 29" wheels. This updated version features tough Broski Sliding Dropouts that allow you to go single-speed or geared or even run hub gears and slightly more modern geometry. Also new is internal seat tube dropper post routing. A modified chainstay allows fitting even some double cranks with “plus size” 2.8" wide tires without needing to invest in Boost 148 parts. We even offer a belt-drive ready version if you want to run a Gates Carbon Drive. (*Belt-drive version works with regular chains as well)
– Tange Prestige heat-treated butted CrMo steel; butted CrMo rear end
– Geometry is optimized for 100mm travel 29" forks and will handle 120mm forks great, too (Ideal rigid fork length: 485mm)
– Disc brakes only (ISO tabs)
– Standard or Belt-Drive compatible versions available (split for installing belt is on the seatstay.)
– IRD Broski Sliding Dropouts allows geared and single-speed builds with easy wheel removal
– In 2021 these come ready for 142 x 12mm Thru-Axle hubs. (Can be converted to 135mm spacing for traditional QR hubs with IRD aftermarket inserts)
– S-bend seatstays and chainstays
– Rear rack and fender eyelets
– CNC-machined 44mm headtube: Will take 1-1/8" steerers with a ZeroStack 44 headset or tapered steerers with a ZS44 upper assembly and external cup (EC44) lower assembly
– 31.6mm post size/34.9mm frt. der. size/34.9mm seat collar/73mm bottom bracket (English threads); 400mm+ post recommended
– Recommended tire size: 29" x 2.4" (or 27.5 x 2.8”)$2,150.00 (RRP) -
Stock Code:SMFR903302Stock Code:SMFR903301Stock Code:SMFR903300Stock Code:SMFR903303
The Juice is our trail/XC hardtail frame for 29? wheels. This updated version features tough Broski Sliding Dropouts that allow you to go single-speed or geared or even run hub gears and slightly more modern geometry. Also new is internal seat tube dropper post routing. A modified chainstay allows fitting even some double cranks with “plus size” 2.8? wide tires without needing to invest in Boost parts. We even offer a belt-drive ready version.
– Tange Prestige heat-treated butted CrMo steel; butted CrMo rear end
– Geometry is optimized for 100mm travel 29? forks and will handle 120mm forks great, too
– Disc brakes only (ISO tabs)
– Standard or Belt-Drive compatible versions available (split for installing belt is on the seatstay.)
– IRD Broski Sliding Dropouts allows geared and single-speed builds with easy wheel removal
– S-bend seatstays and chainstays
– Rear rack and fender eyelets
– CNC-machined 44mm headtube: Will take 1-1/8? steerers with a ZeroStack 44 headset or tapered steerers with a ZS44 upper assembly and external cup (EC44) lower assembly
– 31.6mm post size/31.8mm frt. der. size/34.9mm seat collar/73mm bottom bracket (English threads); 400mm+ post recommended
– 135mm spacing for traditional QR hubs. Old school, yes, but upgradable to 142 x 12mm Thru-Axle with new inserts.
– Recommended tire size: 29? x 2.4? (or 27.5 x 2.8”)
– Color: Battleship Gray$2,050.00 (RRP)$2,040.00 (RRP)$2,050.00 (RRP)$2,050.00 (RRP) -
Stock Code:SMSD38651
Features superlight padding and a modern low-profile form. Fairly flat top for good sit-bones support with comfort vent to reduce perineal pressure. Available in multiple colors with minimalistic graphics. Brown cover is genuine leather.
- Comfort vent base
- Durable CrMo rails
- Longer rails for maximum adjustability
- Superlight padding
- Synthetic leather cover (Genuine leather on the brown) - Colors: Black, red, blue, white, brown
- 133 x 270mm$100.33 (RRP) -
Stock Code:SMSP39456
Soma Seatpost Black 27.2mm
- Forged alloy
- Length 350mm
- Single bolt clamp
- Sand blasted finish$88.20 (RRP) -
Stock Code:SMRK18517
Great little aluminum rack. Perfect for strapping a Wald basket to, or on its own.
Stainless hardware, includes mounting tang and spacers so that you can clear the fork leg when you mount to the eyelets on the backside of your fork.
Works well with a set of P-clamps as well.
Platform measures 240mm x 130mm, eyelet to bottom of rack is 365mm.
Redesigned with eyelets for accessories and taller tombstone (backstop).
The weight limit for the Lucas 3 is 10kg/22 lbs.$180.00 (RRP)Add To Cart
-
Stock Code:SMRK18516
Great little aluminum rack. Perfect for strapping a Wald basket to, or on its own.
Stainless hardware, includes mounting tang and spacers so that you can clear the fork leg when you mount to the eyelets on the backside of your fork.
Works well with a set of P-clamps as well.
Platform measures 240mm x 130mm, eyelet to bottom of rack is 365mm.
Redesigned with eyelets for accessories and taller tombstone (backstop)
The weight limit for the Lucas 3 is 10kg/22 lbs$180.00 (RRP)Add To Cart
-
Stock Code:SMHB27731
6061-T6 shotpeened aluminum handlebar that offers multiple hand positions for comfortable riding. Will accommodate bar end shifters.
- Width: 505mm
- Drop: 60mm
- 25.4mm clamp diameter
- 23.8mm grip diameter
- Weight: 320g$113.56 (RRP) -
Stock Code:SMHB27782
Similar in shape to the Nitto Moustache Bar (and our 3-Speed Bar), but designed for flat bar levers and grips instead of aero levers and tape. Offers multiple hand positions for comfortable riding.
Update 11/1/11: We have just changed the drop from 35mm to 50mm.
- 6061-T6 aluminum
- Clamp diameter 25.4mm
- Grip diameter 22.0mm
- Width 540mm
- Drop 50mm
- Polished silver
- Weight 320 gm$113.56 (RRP) -
Stock Code:SMFK231913
A rigid fork for early 90's mountain bikes with 1" threaded steerer forks. The length is good match for a frame that was designed for a Rock Shox Judy 63mm travel fork.
Measure your current suspension fork at its recommended sag to determine if this rigid fork is a good replacement for your bicycle.
– Tange Chromoly steel
– Axle to crown: 425mm
– Cantilever bosses (no disc mounts)
– Rake: 40mm
– 50mm of threads
(26" wheels only of course)POA -
Stock Code:SMHB27845
29ers have a naturally high front end. This is also true of 26ers with long travel forks. This may result in an undesirably upright ride position. The Odin gives you the extra sweep of a riser bars without the rise. Rotate slightly to add a bit of downward or upward sweep.
- Tange Aluminum
- Width: 715mm (28.15")
- Shotpeen Black
- 25.4 mm center
- 15° sweep
- Zero rise
- 360 grams
.$113.56 (RRP) -
Stock Code:SMPA35635
- The only steel toe clip in production
- Xtra tall to fit boots and skate shoe
- Chrome
- Sizing: Generally, Small-Medium up to US Men's 9, Large-XLarge US Men's 9 and bigger. Also depends on preferences and shoe design.
.$45.20 (RRP) -
Stock Code:SMHB27736$113.56 (RRP)
-
Stock Code:SMHB260011
Swept back town bike handlebar with generous width and leverage. Good option when using a porteur rack, basket or bar bag, since it doesn't sweep too forward.
• 6061-T6 aluminum
• Polished finish, silver or black
• Width: 650mm
• Rise: 25mm
• Center: 31.8mm
• Grip Area Diameter: 22.2mm
• Grip Area Length: 160mm
• Backsweep: 73°
• The internal diameter of the ends are machined to fit some bar end shifters and reverse brake levers.
• Bends forward 22° before bending backwards.
• Weight: 465 grams$144.00 (RRP) -
Stock Code:SMHB260012
Swept back town bike handlebar with generous width and leverage. Good option when using a porteur rack, basket or bar bag, since it doesn't sweep too forward.
• 6061-T6 aluminum
• Polished finish, silver or black
• Width: 650mm
• Rise: 25mm
• Center: 31.8mm
• Grip Area Diameter: 22.2mm
• Grip Area Length: 160mm
• Backsweep: 73°
• The internal diameter of the ends are machined to fit some bar end shifters and reverse brake levers.
• Bends forward 22° before bending backwards.
• Weight: 465 grams$144.00 (RRP) -
Stock Code:SMRK185710
Front mini rack with a host of braze-ons for your gadgets. This one has wider-set stays to fit gravel forks like the Enve Adventure series.
Extra long tang is bent for mounting to caliper brake bolt.
P-Clamps and other hardware included.
If installing to a braze-on, the braze-on need to be about 140mm from the brake hole on the crown. If your braze-on is too low, you will need to install using P-clamps on the legs.POA -
Stock Code:SMRK185711
Front mini rack with a host of braze-ons for your gadgets. This one has wider-set stays (130mm) to fit gravel forks like the Enve Adventure series.
Extra long tang is bent for mounting to caliper brake bolt on fork crown.
Hardware included.
Fits best on forks where the caliper brake hole on fork crown is 140mm above the fork leg eyelets. P-clamps included for steel forks that don't have eyelets. (P-clamps usually don't fit on tear drop shaped fork legs.)$210.00 (RRP)Add To Cart
-
Stock Code:SMRK185745
Includes two axle plates that attach to the legs of the rack, 2 pairs of nuts/bolts.
$45.00 (RRP)Add To Cart
-
Stock Code:SMCL19690$54.02 (RRP)
Add To Cart
-
Stock Code:SMHB27869Stock Code:SMHB27872Stock Code:SMHB27801
The Sparrow is a touring/townie bar. The 490mm version is more agile for squeezing through traffic than other townie/MTB bars. The 520mm is still narrow, but with a grip area that fits levers and shifters. The 560mm size is better for climbing and single-speeders. Try all the sizes on a single-speed or fixie. Can be used flipped to be used as a riser bar or down for a less upright position.
- Shotpeened Tange Aluminum
- Widths: 560 mm, 520mm or 490mm
- Silver or Black
- 25.4 mm clamp diameter
- 50mm drop/rise
- 22.2mm grip diameter, 20.0mm inside diameter at ends to allow use of pursuit levers.
- Weight 245g$113.56 (RRP)$113.56 (RRP)$113.56 (RRP) -
Stock Code:SM268004
Slender profile stem looks great on a steel bike. Tall 80mm steerer clamp reduces need for headset spacers.
- Minimum insertion is 40mm
– TIG-welded CrMo steel
– Single bolt clamp for either 26.0mm bars or 31.8mm bars
– Steerer pinch bolt is located in front to avoid painful knee contact
– Angle: 17°
– Chrome-plated
– Weight: 200g (110mm)$199.00 (RRP)Add To Cart
