Wheels Manufacturing
-
Stock Code:WMBB-BBSEAL-SRAMStock Code:WMBB-24MMSEAL
24mm Outer Silicone Seal for Bottom Brackets
Outer seal for Wheels Mfg BB86/92, PF30-OUT, BB30-OUT, BB-ROAD, BB-MTN bottom brackets.
Note: Install seals with rubber-side facing away from bearing.
24mm ID for Drive-Side cup (Both Shimano and SRAM)
24mm ID for Non-Drive Side cup with 24mm crank spindle (Shimano, FSA, etc)
* Sold Individually$15.00 (RRP)$10.00 (RRP) -
Stock Code:WMBB-BB-24MM-0.5Stock Code:WMBB-BB-24MM-1.0
Used to adjust crank chainline or take up any slack when using 24mm (Shimano, FSA, etc.) or 24/22mm (SRAM/TruVativ) Spindle Cranks in any BB30/PF30/BB86/92 or similare crank system.
- 24mm I.D. for use with cranks like Shimano HollowTech II, GXP, FSA
- 30mm I.D. for use with BB30 cranks
- 10 spacers per bag
- Machined engineering-grade Delrin.$29.00 (RRP)$29.00 (RRP) -
Stock Code:WMBB-WAVEWSH-24MM-10Stock Code:WMBB-WAVEWSH-30MM-10
Used to take set proper side-load in PF30, BB30 and similar bottom bracket systems when using 30mm, 24mm (Shimano, FSA, etc.) or 22/24mm (SRAM/TruVativ) spindle cranks.
- Choose from 30mm I.D. or 24mm I.D.
- Sold 10 washers per bag$45.00 (RRP)$45.00 (RRP) -
Stock Code:WMBB-BB-29MM-0.5Stock Code:WMBB-BB-29MM-1.0Stock Code:WMBB-BB-29MM-2.5-5
Used to adjust crank chainline or take up any slack when using 29mm (SRAM DUB) spindle cranks.
- 29mm I.D.
- 2.5mm thick
- 5 spacers per bag
- Machined engineering-grade Delrin.$29.00 (RRP)$29.00 (RRP)$29.00 (RRP) -
Stock Code:WMTL-29SRAM-OB
29mm open bore adapter is used to press 29mm x 42mm (DUB) sealed bearings. The adapter is machined with one step at 29mm OD, which fits into the center of the sealed bearing. For use with Wheels Mfg Bottom Bracket Press (PRESS-7, PRESS-7-PRO or PRESS-9-PRO)
Installs: 29X42 (DUB) bearing
Inner Step Outer Diameter: 41.8mm
Outer Diameter: 28.9mm
Thru Hole Diameter: 12.8mm (1/2")
Thickness: 7mm
Compatible with PRESS-7, PRESS-7-PRO or PRESS-9-PRO handles/rod.
Machined, red anodized aluminum
Sold individually$18.00 (RRP)Add To Cart
-
Stock Code:WMBB-PF30-0.5MM-10Stock Code:WMBB-PF30-1.0MM-10
Used to adjust crank chainline or take up any slack when using 30mm, 24mm (Shimano, FSA, etc.) or 24/22mm (SRAM/TruVativ) Spindle Cranks in any BB30/PF30/BB86/92 or similare crank system.
- 24mm I.D. for use with cranks like Shimano HollowTech II, GXP, FSA
- 30mm I.D. for use with BB30 cranks
- 10 spacers per bag
- Machined engineering-grade Delrin$28.90 (RRP)$28.90 (RRP) -
Stock Code:WMBB-BB30-30-5MMStock Code:WMBB-BB30-30-10MM
Used to adjust crank chainline or take up any slack when using 30mm spindle cranks.
Inner Diameter: 30mm
Outer Diameter: 41.5mm
Thickness: 10mm
Sold Individually$13.00 (RRP)$17.00 (RRP) -
Stock Code:WMBB-386EVO-SRAM
Wheels MFG 386EVO Adapter For SRAM Crank (1x 24mm ID Adapter Right, 1x 22mm ID Adapter Left, 8x 0.7mm spacers)
For adapting SRAM/Truvativ cranks to 386EVO-standard frames$124.00 (RRP)Add To Cart
-
Stock Code:WMBB-386EVO-SHIM
Wheels MFG 386EVO Adapter for Shimano Cranks (2x 24mm ID Adapters & 8x 0.7mm Spacers)
For adapting Shimano cranks to 386EVO-standard frames.$124.00 (RRP)Add To Cart
-
Stock Code:WMBB-386EVO-BB29MM
Thread together BB for 386EVO frames and 29mm spindle diameter SRAM DUB compatible cranks. Machined aluminum cups thread together for stability, increased bearing life, and simple installation and maintenance.
No more creaking. Smooth operation. Fast bearing replacement.
Bottom Bracket Includes:
BB Cups with bearings
2 - Silicone dust seals
2 - 0.5mm crank spindle spacers
2 - 1.0mm crank spindle spacers
1 - 2.5mm crank spindle spacer$216.00 (RRP)Add To Cart
-
Stock Code:WMBB-386EVO-BB-AC
Threaded BB for 386EVO frames. Machined cups thread together for stability, increased bearing life, and simple installation and maintenance. In Angular Contact (A/C) bearings, ALL balls are engaged and spread the force over a larger surface area, to decrease friction and minimize wear.
No more creaking. Smooth operation. Fast bearing replacement.
Note: Use only bottom bracket tools compatible with 16-notch MegoEvo BB’s. (FSA MegaEvo and Park Tool BBT-29).
Bearings: Enduro Angular Contact
Bottom Bracket/Frame Interface: BB386EVO
Bottom Bracket Shell Width (mm): 86.5mm
Bottom Bracket Shell I.D.: 46mm
Crank Spindle Diameter: 30mm
Weight: 126g
*Will accept 24mm and 24/22mm cranksets using Wheels Mfg. 386EVO BB / Crank AdaptersExpected Date:20 January 2025$230.00 (RRP) -
Stock Code:WMBB-386EVOBB-SHIMAC
Threaded BB for 386EVO frames and 24mm diameter spindle cranks. Machined cups thread together for stability, increased bearing life, and simple installation and maintenance. In Angular Contact (A/C) bearings, ALL balls are engaged and spread the force over a larger surface area, to decrease friction and minimize wear.
No more creaking. Smooth operation. Fast bearing replacement.
Bottom Bracket/Frame Interface: BB386EVO, BB392EVO
Bottom Bracket Shell Width (mm): 86.5mm
Bottom Bracket Shell I.D.: 46mm
Crank Spindle Diameter: 24mm$230.00 (RRP)Add To Cart
-
Stock Code:WMBB-386EVOBB-SRAMAC
Threaded BB for 386EVO frames and 22/24mm diameter spindle cranks. Machined cups thread together for stability, increased bearing life, and simple installation and maintenance.In Angular Contact (A/C) bearings, ALL balls are engaged and spread the force over a larger surface area, to decrease friction and minimize wear.
No more creaking. Smooth operation. Fast bearing replacement.
Notes:
Wheels Mfg 386EVO BB for use with 24/22mm spindle cranks will not work with Quarq SRAM/GXP cranksets (Elsa, Riken, SRAM Red 22, SRAM S975, SRAM S2275, CinQo Saturn, Saturn2). If your Quarq spider has an ID less than 49.5mm, your crank may rub on the BB cup.
Compatible with Quarq DZero powermeter spiders with GXP spindles except Eagle MTB.
Bottom Bracket/Frame Interface: BB386EVO, BB392EVO
Bottom Bracket Shell Width (mm): 86mm - 92mm
Bottom Bracket Shell I.D.: 46mm$230.00 (RRP)Add To Cart
-
Stock Code:WMBB-386EVO-BB
Threaded BB for 386EVO frames. Machined cups thread together for stability, increased bearing life, and simple installation and maintenance.
No more creaking. Smooth operation. Fast bearing replacement.
** Note: Use only bottom bracket tools compatible with 16-notch MegoEvo BB’s. (FSA MegaEvo and Park Tool BBT-29).**
Bearings: Enduro ABEC-3
Bottom Bracket/Frame Interface: BB386EVO
Bottom Bracket Shell Width (mm): 86.5mm
Bottom Bracket Shell I.D.: 46mm
Crank Spindle Diameter: 30mm
Weight: 126g
*Will accept 24mm and 24/22mm cranksets using Wheels Mfg. 386EVO BB / Crank Adapters$216.00 (RRP)Add To Cart
-
Stock Code:WMBB-386EVOBB-PRX
Thread together BB for 386EVO frames and M30 28/30mm diameter spindle Praxis - Compatible cranks. Machined aluminum cups thread together for stability, increased bearing life, and simple installation and maintenance.
Bottom Bracket/Frame Interface: BB386EVO, BB392EVO
Bottom Bracket Shell Width (mm): 86mm - 92mm
Bottom Bracket Shell I.D.: 46mm
Crank Spindle Diameter: 28/30mm
Over Bearing Width: 91.8mm in 86.5mm wide shellExpected Date:20 January 2025$216.00 (RRP) -
Stock Code:WMBB-386EVOBB-SHIM
Threaded BB for 386EVO frames and 24mm diameter spindle cranks. Machined cups thread together for stability, increased bearing life, and simple installation and maintenance.
No more creaking. Smooth operation. Fast bearing replacement.
Bottom Bracket/Frame Interface: BB386EVO, BB392EVO
Bottom Bracket Shell Width (mm): 86.5mm
Bottom Bracket Shell I.D.: 46mm
Crank Spindle Diameter: 24mm
Bearings: Enduro ABEC-3Expected Date:20 January 2025$216.00 (RRP) -
Stock Code:WMBB-386EVOBB-SRAMBB
Threaded BB for 386EVO frames and 22/24mm diameter spindle cranks. Machined cups thread together for stability, increased bearing life, and simple installation and maintenance.
No more creaking. Smooth operation. Fast bearing replacement.
Notes:
Wheels Mfg 386EVO BB for use with 24/22mm spindle cranks will not work with Quarq SRAM/GXP cranksets (Elsa, Riken, SRAM Red 22, SRAM S975, SRAM S2275, CinQo Saturn, Saturn2). If your Quarq spider has an ID less than 49.5mm, your crank may rub on the BB cup.
Compatible with Quarq DZero powermeter spiders with GXP spindles except Eagle MTB.
Bottom Bracket/Frame Interface: BB386EVO, BB392EVO
Bottom Bracket Shell Width (mm): 86mm - 92mm
Bottom Bracket Shell I.D.: 46mm
Bearings: Enduro ABEC-3$216.00 (RRP)Add To Cart
-
Stock Code:WMBB-386EVO-CER-ZERO
Threaded BB for 386EVO frames. Machined cups thread together for stability, increased bearing life, and simple installation and maintenance.
No more creaking. Smooth operation. Fast bearing replacement.
Note: Use only bottom bracket tools compatible with 16-notch MegoEvo BB’s. (FSA MegaEvo and Park Tool BBT-29).
Bearings: Enduro ZERØ Ceramic Hybrid
Bottom Bracket/Frame Interface: BB386EVO
Bottom Bracket Shell Width (mm): 86.5mm
Bottom Bracket Shell I.D.: 46mm
Crank Spindle Diameter: 30mm
Weight: 126g
*Will accept 24mm and 24/22mm cranksets using Wheels Mfg. 386EVO BB / Crank Adapters$445.00 (RRP)Add To Cart
-
Stock Code:WMBB-PF30-SPEED-SEAL
42mm OD / 30mm ID Outer Seals (each)
Outer dust seal for 6806 bearings. 30mm inner diameter fits over 30mm diameter crank spindles. 42mm outer diameter covers the outer race of a 6806 bearing. This is a light duty dust seal with minimal sealing abilities. This seal is 1mm thinner than seals provided with our bottom brackets for 30mm diameter spindles.
- Inner Diameter: 30mm
- Outer Diameter: 42mm
- Thickness: 1.5mm
- Replacement seal for our BB86-30-BB and BB86-30-CER bottom brackets.
** Sold Individually
Note: Installl with the embossed lettering facing the bearing.$19.00 (RRP)Add To Cart
-
Stock Code:WMBB-SP0001
46mm inside diameter cup spacers that fit between a bottom bracket cup and the frame. Machined from 6061 aluminum and anodized black. These spacers can be used for a few different scenarios:
When used with a Wheels Manufacturing GXP compatible bottom bracket, adding cup spacers between the non-drive side cup and the frame will move the chainrings on a GXP crank closer to the frame (reducing the chainline).
For Specialized road frames with the 61mm wide Carbon OSBB shell, you would place 3.5mm of spacers betwen each cup to effectively widen the BB shell to 68mm when used with non-Specialized cranks. One bag will properly space one 61mm wide Specialized OSBB shell to 68mm.
Bag Includes:
(2) - 2.5mm bottom bracket cup spacers (46mm ID)
(4) - 1.0mm bottom bracket cup spacers (46mm ID)$52.00 (RRP)Add To Cart
-
Stock Code:WMCE-CA0003
Precision-machined 4mm ID silver aluminum cable ferrules for improved shifting performance. A flat bottom on the inside prevents housing from pulling through ferrules. For use with most shifting cables.
- Inside Diameter: 4mm
- Outside Diameter: 5.75mm
- Overall Length: 12.7mm
- Color: Silver
- Material: Aluminum
- Bottle of 50pcs$78.00 (RRP)Add To Cart
-
Stock Code:WMCE-CA0001
Precision-machined 4mm ID brass cable ferrules for improved shifting performance. A flat bottom on the inside prevents housing from pulling through ferrules. For use with most shifting cables.
- Inside Diameter: 4mm
- Outside Diameter: 5.75mm
- Overall Length: 12.7mm
- Color: Gold
- Material: Brass
- Bottle of 50pcs$48.00 (RRP)Add To Cart
-
Stock Code:WMBG-BALLRET5/16X12
Wheels MFG 5/16"x12 Bearing Retainer 10 per bag Suit BMX 1 Piece Bottom Bracket
$41.00 (RRP)Add To Cart
-
Stock Code:WMCE-CA0008
Precision-machined ferrules for improved braking and shifting performance. A flat bottom on the inside prevents housing from pulling through ferrules.
- 5mm inside diameter
- Silver aluminum
- Bottle of 300$285.00 (RRP)Add To Cart
